Built for big jobs, the ZT XL has been redesigned with an 11 gauge fabricated X-Factor deck, vibration isolators and a high-back seat to combine professional cut quality, durability and comfort while mowing multiple acres.
- One-piece, fully welded tubular chassis displays strength and durability with its closed tube frame rails and fully welded construction techniques influenced by our commercial applications.
- X-FACTOR® 11-Gauge fabricated deck - Inspired by our commercial machines, this all new 4.5 inch-deep steel deck optimizes airflow, and the reinforced sloped nose allows more room for grass to stand up ahead of the cutting chamber for our best cut ever on a residential machine. Caged anti-scalp wheels make your lawn less susceptible to damage from minor bumps and scrapes.
- Hydro-Gear® ZT-2800® serviceable transaxles have optimized cooling to ensure smooth running for years to come. Integrated service ports on the internal reservoirs and a replaceable filter allow fluid changes for easy maintenance.
- Taller and wider seat with padded armrests - Ready for the long mow! The seat is 55cm tall to provide more back support and is mounted on a taller seat base to make it easier to stand up and sit down. Padded armrests deliver extra cushion to keep your arms more comfortable.
- Dual USB-A ports
- Dual high intensity LED headlights
- Tool-less quick adjust control arms
- Tool-less flip up floor plate with accessory tray
- Machine Warranty - 4 Years or 400 Hours
- POWERED BAGGER KIT, 2-BUCKET BAGGER, TRAILER HITCH KIT, MULCHING KIT, WHEEL COVER KIT
Specifications
Engine Make
Kawasaki®
Engine Model
Kawasaki® FR 691 V-Twin
Displacement
726 CC
Fuel Tank Capacity
13.2 L
Engine Capacity
23 HP
Cutting Width
48"
Cutting Height Range
38 MM - 114 MM
Cutting Positions Spec
13
Drive System
Hydro-Gear® ZT-2800®
Forward Speed
0 - 11.3 KM/H
Reverse Speed
0 - 4.8 KM/H
Seat Type
55cm tall, plush high back with arm rests and seat slider
Deck Lift
Foot Operated
Deck Fabrication
Fabricated X-Factor®
Deck Engagement
Electric Warner
Spindle Housing
Forged Aluminum
Number of Spindles
3
Spindle Housing Material Spec
Forged Aluminum
Front Wheels
Smooth Pneumatic
Rear Wheels
Aggressive Tread Turf
Front Tyres Size
11 IN X 6 IN - 5 IN
Rear Tyres Size
20 IN X 8 IN - 8 IN
Weight
308.0kg
Product Dimensions (W x H x L)
1582 MM (with Chute) X 1168 MM X 1892 MM
